180Hp-1440 Rpm Foot Mounted Phase - 3

Get a Price/Quote

Product Details:

Horse Power 180 Hp
Standard IS 325
Pressure Standard Atmospheric
Torque 1192 Nm
Current Type AC
Rated Frequency 50 Hz
Motor Type Induction Motor
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

180Hp-1440 Rpm Foot Mounted Phase - 3 Price And Quantity

Minimum Order Quantity 1 Piece

180Hp-1440 Rpm Foot Mounted Phase - 3 Product Specifications

Color Blue
Mounting Type Foot Mounted
Product Type Electric Motor
Cooling Method Air Cooled
Bearing Type Heavy Duty Ball Bearing
Efficacy High Efficiency
Poles Number 4
Weight 1150 kg
Ambient Temperature -15C to 40C
Shaft Diameter 80 mm (approx)
Noise Level Within permissible limits
Voltage 415 V
Starting Type Direct On Line (DOL)
Sealed Type TEFC
Rated Voltage 415 V
Protect Feature Totally Enclosed Fan Cooled (TEFC)
Output Power 180 Hp
Phase Three Phase
Motor Type Induction Motor
Rated Frequency 50 Hz
Current Type AC
Power 134.2 kW
Power Rating 180 Hp / 134.2 kW
Features Robust Design, Long Life, Low Maintenance
Horse Power 180 Hp
Frequency (MHz) 50 Hz
Standard IS 325
Speed 1440 RPM
IP Rating IP55
Pressure Standard Atmospheric
Dimension (L*W*H) Custom as per manufacturer
Torque 1192 Nm

Duty Type S1 Continuous
Frame Size 355 S/M
Balancing Dynamically Balanced
Insulation Class Class F
Vibration Level As per IS 12075
Application Industrial, Pumps, Compressors, Blowers
Non Drive End Bearing 6319/C3
Finish Industrial Grade Paint
Drive End Bearing 6319/C3
Service Factor 1.15
Starting Current 6-7 times Full Load Current
Efficiency at Full Load ~95%
Rotation Direction Both Directions

Product Description

Grab this phenomenally engineered 180Hp-1440 Rpm Foot Mounted Phase-3 Induction Motor, a renowned best-seller among India's industrial sector. Designed for transcendent performance, it features a robust cast that supports high durability and reliability. With an impressive efficiency of ~95% and virtually maintenance-free operation, this motor delivers output power of 134.2 kW, perfectly suited for pumps, compressors, and blowers. The dynamically balanced shaft and IP55 TEFC enclosure ensure smooth, vibration-free operation for continuous duty. Don't miss unbeatable discount offers for a limited time!

Application, Features & Usage Directions

The 180Hp-1440 Rpm Foot Mounted Phase -3 motor is ideal for demanding industrial applications, including pumps, compressors, and blowers. Its robust design, high efficiency, and dynamically balanced construction guarantee extended service life and low operational noise. With the ability to rotate in both directions, this motor ensures flexibility in installation and operation. For optimal results, install the motor on a stable foot-mounted surface and connect to a three-phase DOL system as per manufacturer's guidelines.

Domestic Market, Dispatch & Certifications

This motor is highly preferred in the domestic market due to its reliability and quick dispatch. Timely arrival is ensured with streamlined logistics across India. Certified under IS 325 standard, the 180Hp-1440 Rpm Foot Mounted Phase - 3 motor adheres to stringent national quality norms, making it a trusted choice for a wide spectrum of industrial projects. Certifications and efficient delivery underscore our commitment to customer satisfaction.

FAQ's of 180Hp-1440 Rpm Foot Mounted Phase - 3:

Q: How is the 180Hp-1440 Rpm Foot Mounted Phase-3 motor best used in industrial settings?

A: It is designed for continuous use in demanding environments like pumps, compressors, and blowers, offering high efficiency, robust performance, and long operational life.

Q: What features make this induction motor a best-seller in India?

A: Its phenomenal build, high efficiency (~95%), dynamically balanced shaft, both-direction rotation, and robust, low-maintenance construction make it a top choice for industrial use.

Q: Where can the 180Hp-1440 Rpm motor be delivered, and how fast?

A: We offer quick dispatch with nationwide delivery across India. Our streamlined supply chain ensures prompt arrival at your industrial location.

Q: What certifications does this motor come with?

A: It is certified under IS 325, ensuring alignment with rigorous Indian quality standards for performance and safety.

Q: How should the motor be installed for optimal performance?

A: Mount it on a stable foot-mounted base, connect to a three-phase power source through Direct On Line (DOL) starting, and follow the supplied manufacturer's installation guide.
